Product Details:
|
| Roller Material: | Cr12, Heat Treatment | Roller Stations: | 18 Stations |
|---|---|---|---|
| Control System: | PLC | Cutting Length Tolerance: | ±1mm |
| Forming Speed: | 10m/min | Motor Power: | 18.5KW |
| Material Thickness: | 1.5mm To 2.0mm | Product Name: | Racking System Roll Forming Machine |
| Highlight: | 18.5KW Racking Roll Forming Machine,Racking Roll Forming Machine Custom,18.5KW Upright Roll Forming Machine | ||
This roll forming machine is for making shelving profile, it features a series of 18 stations with precisely machined rollers. It is driven by two 18.5KW motors and it is suitable for forming materials like galvanized steel with material thickness up to 2.0mm. The cutting length tolerance is within ±1mm.
Drawing:
| ROLL FORMING MACHINE FOR UPRIGHT PROFILE(DOUBLE SIDES) | |
| Material Specification | |
| Thickness | 1.5mm to 2.0mm or customized |
| Size | YX50.3/56.5-80,YX59.8/66.5-90 |
| Material | GI, cold rolled steel |
| Yield strength | 250MPa or customized |
| Machine Components | |
| 5Ton*600mm Hydraulic Decoiler | |
| Coil inner hole expanding | Hydraulic system, 3KW pump motor |
| Speed regulating | Frequency inverter, 3KW motor |
| Expanding type | Taper wedge expanding system |
| Load capacity | Max.5Tons |
| Coil Inner-diameter | 510±30mm |
| Coil width | Max.600mm |
| Stop/start rotation | Automatic stopping device with limited switch to assist |
| Pre-leveler and Power Feed-in Device (DOUBLE SIDES) | |
| Power Feed-in Rollers | |
| Pre-Level Device with 4 over 3 shafts to remove the Coil-set | |
| Power | 5.5KW |
| 100 Tons Press | |
| Servo motor feed-in device | 3KW |
| Quantity of pressing tools | 5 sets |
| Mateiral of pressing tool | Cr12Mov, heat treatment |
| Holes patten | Customized |
| Hydraulic Pre-shearing Device(as an Option) | |
| Function | Smart cut control, to cut off the end of the final piece of sheet |
| Mateiral of cutting tool | Cr12, heat treatment |
| Roll Forming Machine | |
| Driving system | Gear/sprocket |
| Forming station | Double sides, each side 18 stations |
| Roller material | Cr12, heat treatment, HRC58~62 |
| Shafts Diameter | Φ75mm |
| Motor to drive | 18.5KW, two sides share the same motor, doesn't work at the same time |
| Size changing | By spacer |
| Production speed | Approx. 8m/min to 10m/min |
| Hydraulic Non-Stop Cutting device | |
| Cutting type | Non-stop cut, no blanking cut |
| Quantity of cutting tools | 2 sets |
| Cutting tool material | Cr12, heat treatment |
| Hydraulci pump motor | 11KW |
| Air souce supply | By user |
| PLC Control System | |
| Function | Control quantity, punching and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Schneider or Delta |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±1 mm |
| Punching tolerance | ≤±1 mm |
| Control Voltage | 24V |
| Product Rack | Un-powered, 6 meters |
| Option | Pneumatic unloading rack |
Applications:
The Racking System Roll Forming Machine from XIAMEN FUMING is designed to manufacture shelf and upright profiles for racking systems from galvanized steel with a material thickness up to 2.0mm. This roll forming machine is equipped with a hydraulic cutting system, ensuring a precise cutting length tolerance of ±1mm. This roll forming machine is suitable for metal sheet processing and is widely used in storage system.
We provide technical support and service for Racking System Roll Forming Machine. Our professional team is available 24/7 to provide you with prompt and reliable support. Our technical support services include:
We are committed to providing you with the highest level of technical support and service. If you have any questions or concerns, please do not hesitate to contact us.
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
