Product Details:
|
| Roller Stations: | 8 Stations | Roller Material: | Cr12, Heat Treatment, HRC58~62 |
|---|---|---|---|
| Material Thickness: | 3.2mm | Product Name: | Racking System Roll Forming Machine |
| Motor Power: | 11KW | Forming Speed: | 20m/min |
| Material Type: | Galvanized Steel | Control System: | PLC |
| Highlight: | Precision Racking Roll Forming Machine,Racking Roll Forming Machine L Shape,11KW Precision Roll Forming Machine | ||
L Shape Roll Forming Machine for L96/71/58mm Profiles
L Shape Roll Forming Machine is a kind of machine specially used in producing L shape profile. It uses rollers to form the material into pre-determined shapes. The forming speed of this machine is 20m/min, with cutting length tolerance of ±2mm, and the material thickness can be adjusted up to 3.2mm. It is equipped with a PLC control system and hydraulic cutting system, ensuring high accuracy and reliability of the products.
Drawing:
| ROLL FORMING MACHINE FOR L ANGLE | |
| Material Specification | |
| Thickness | 3.2mm |
| Size | 96/71/58mm |
| Material | GI, Hot rolled steel |
| Yield strength | 250~400Mpa |
| Machine Components | |
| 5Ton*600mm Hydraulic Decoiler | |
| Coil inner hole expanding | Hydraulic system, 3KW pump motor |
| Speed regulating | Frequency inverter, 3KW motor |
| Expanding type | Taper wedge expanding system |
| Load capacity | Max.5Tons |
| Coil inner diameter | 510±30mm |
| Coil outer diameter | Max.1600mm |
| Coil width | Max.600mm |
| Stop/start rotation | Automatic stopping device with limited switch to assist |
| Option | Please refer to Decoiler on home page |
| Pre-leveling Device | |
| Pre-Level Device with 4 over 3 shafts to remove the Coil-set, Manual control | |
| Roll Forming Machine | |
| Driving system | Gear/sprocket |
| Forming station | 8 stages |
| Shaping device | 5 rollers for shaping |
| Roller material | Cr12, heat treatment, HRC58~62 |
| Option for roller material | Cr12Mov |
| Shafts Diameter | Φ75mm |
| Motor to drive | 11KW |
| Speed | Approx. 20m/min |
| Hydraulic Post Cutting Device | |
| Cutting type | No blanking cut |
| Cutting tool material | Cr12, Heat treatment |
| Hydraulic station | 7.5KW |
| PLC Control System | |
| Function | Control quantity, punching and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Schneider or Delta |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±2mm |
| Control Voltage | 24V |
| Product Rack | Un-powered, 3 meters long |
XIAMEN FUMING's L Shape Roll Forming Machine is specially designed and manufactured for L96/71/58 production. With galvanized steel as the material, this machine is able to make the material thickness of 3.2mm. It is featured with PLC control system, and the cutting length tolerance is ±2mm, which ensures high precision. The price is negotiable and the machine is shipped without outer packing, shipped by container.
We provide technical support and service for Roll Forming Machine, including:
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
.jpg "12.jpg")
.jpg "13.jpg")
