Product Details:
|
| Transmission: | Gear/sprocket | Roller Material: | 45# Steel, Hard Chrome Coated |
|---|---|---|---|
| Material: | PPGI | Power: | 7.5KW |
| Control System: | PLC Control | Forming Speed: | 15m/min |
| Cutting Type: | Hydraulic Cutting | ||
| Highlight: | Cladding Roof Panel Roll Forming Machine,Profile Roof Panel Roll Forming Machine,Profile Cladding Roll Forming Machine | ||
Cladding Panel Roll Forming Machine for YX40-300 Profile
The Cladding Panel Roll Forming Machine is designed to meet the high performance requirements. It adopts the PLC control system, transmission with gear/sprocket, and has a high precision cutting length. This Cladding Panel Roll Forming Machine is ideal for producing cladding panels with high accuracy, high efficiency and stable performance. With a wide range of applications, it is an ideal choice for cladding panel forming operation. Its advanced technology ensures a reliable, efficient and safe operation in various environments.
Drawing:
| ROLL FORMING MACHINE FOR YX40-300 CLADDING PROFILE | |
| Material Specification | |
| Thickness | 0.4mm to 0.8mm |
| Effective width | 300mm |
| Feeding width | Approx.500mm |
| Material | PPGI |
| Yield strength | 250MPa |
| Machine Components | |
| Roll Forming Machine | |
| Driving system | Gear/sprocket |
| Forming station | 24 stations |
| Roller material | 45# steel, CNC lathes, hard chrome coated |
| Shafts Diameter | Φ75mm |
| Main motor | 7.5KW, frequency speed control |
| Line speed of rollformer | Approx. 15m/min |
| Hydraulic Cutting Device | |
| Cutting type | Slug breaker |
| Cutting tool material | Cr12, heat treatment |
| Hydraulci pump motor | 3KW |
| PLC Control System | |
| Function | Control quantity and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Delta |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±2 mm or customized |
| Control Voltage | 24V |
| Product Rack | Un-powered, three units |
XIAMEN FUMING Cladding Panel Roll Forming Machine, model number YX40-300, is a reliable and cost-effective equipment. The voltage of the equipment can be customized.
We provide comprehensive support for Cladding Panel Roll Forming Machines, including:
Our team of experienced professionals will work with you to ensure your Cladding Panel Roll Forming Machine is running efficiently and reliably.
If you have any questions or require support for your Roll Forming Machine, please contact us.
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
