Product Details:
|
| Cutting Length: | Any Length | Forming Speed: | Approx. 4 To 5m/min While Producing 6 Meters Long Profiled Sheet |
|---|---|---|---|
| Cutting Type: | Hydraulic | Thickness: | 0.35-0.6mm |
| Voltage: | 380V/50HZ/3PH Or Customized | Width: | 910mm |
| Name: | Roof Tile Roll Forming Machine | Usage: | Industrial |
| Highlight: | 3PH Roof Tile Roll Forming Machine,Roof Tile Roll Forming Machine Automatic,Tile Roof Roll Forming Machine Industrial | ||
Roof Tile Roll Forming Machine for YX42-182-910 Profile, Customized Design
This Roof Tile Roll Forming Machine is an ideal choice for metal tile production. It can produce metal tiles with a thickness of 0.35-0.6mm and a width of 910mm. It is driven by a 7.0KW servo motor and uses a hydraulic cutting system. The Roof Tile Roll Forming Machine Line has a good production efficiency, and is known for its high quality and low production cost. It is equipped with PLC control system, which makes it easy to monitor and adjust the production process. The metal sheets produced by this machine have high precision and excellent surface finish, making it a perfect choice for mass production.
Drawing:
| ROLL FORMING MACHINE FOR YX42-182-910 TILE ROOF | |
| Material Specification | |
| Thickness | 0.35mm to 0.6mm |
| Effective width | 910mm |
| Feeding width | Approx.1220mm |
| Material | PPGI |
| Yield strength | 245MPa to 350MPa |
| Machine Components | |
| 5Ton*1250mm Hydraulic Decoiler | |
| Coil inner hole expanding | Hydraulic system, 3KW pump motor |
| Speed regulating | Frequency inverter, 3KW motor |
| Expanding type | Taper wedge expanding system |
| Load capacity | Max.5Tons |
| Coil inner diameter | 510±30mm |
| Coil outer diameter | Max.1600mm |
| Coil width | Max.1250mm |
| Stop/start rotation | Automatic stopping device with limited switch to assist |
| Entry Roller and Manual Pre-shearing Device | |
| Working thickness | Up to 0.8mm |
| Function | Smart cut control, to cut off the end of the final piece of sheet only |
| Roll Forming Machine | |
| Polythene film-on device | To avoid scratch on the surface of aluminum while roll forming |
| Driving system | Gear/sprocket |
| Forming station | 16 stages |
| Roller material | 45# steel, CNC lathes, hard chrome coated |
| Shafts Diameter | Φ75mm |
| Servo motor | 7.0KW |
| Production speed | Approx. 4 to 5m/min |
| Hydraulic Pressiing and Post-cutting Device | |
| Hydraulci pressing | Step height 25mm or customized |
| Cutting type | No Blanking cut |
| Cutting tool material | Cr12, heat treatment |
| Hydraulci pump motor | 11KW |
| PLC Control System | |
| Function | Control pressing, quantity and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±1 mm |
| Control Voltage | 24V |
| Product Rack | Un-powered, three units |
