Product Details:
|
| Roller Material: | 45# Steel, Hard Chrome Coated | Roller Stations: | 20 Stations |
|---|---|---|---|
| Main Motor Power: | 5.5KW | Cutting Tolerance: | ±2mm |
| Product Name: | Door Frame Roll Forming Machine | Material Thickness: | 0.4-0.6mm |
| Control System: | PLC Control | Cutting Method: | Hydraulic Cutting |
| Highlight: | 5.5KW Shutter Roll Forming Machine,Shutter Roll Forming Machine PLC Control | ||
Shutter Door Roll Forming Machine for YX12-62-377 Profile
With easy-to-operate technology, this door frame roll forming machine can make door frame with a cutting tolerance of ±2mm and speed up to 15m/min, making it the good choice for mass production. The machine is also equipped with PLC control system, providing greater accuracy and stability while producing the door frame.
| ROLL FORMING MACHINE FOR YX12-62-377 SHUTTER DOOR | |
| Material Specification | |
| Thickness | 0.4mm to 0.6mm |
| Effective width | 377mm |
| Feeding width | Approx.914mm |
| Material | PPGI |
| Yield strength | 550MPa |
| Machine Components | |
| 3Ton*600mm Simple Decoiler | |
| Load capacity | Max.3Tons |
| Coil inner-diameter | 510±30mm |
| Coil width | Max.600mm |
| Roll Forming Machine | |
| Driving system | Gear/sprocket |
| Option for driving system | Gear box or toroidal worm box |
| Forming station | 20 stations |
| Roller material | 45# steel, CNC lathes, hard chrome coated |
| Option for roller material | Cr12, Cr12Mov |
| Shafts Diameter | Φ75mm |
| Main motor | 5.5KW, frequency speed control |
| Line speed of rollformer | Approx. 15m/min or customized |
| Hydraulic Cutting Device | |
| Cutting type | Slug breaker |
| Cutting tool material | Cr12, heat treatment |
| Hydraulci pump motor | 4KW |
| PLC Control System | |
| Function | Control quantity and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Schneider or Delta |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±2 mm or customized |
| Control Voltage | 24V |
| Product Rack | Un-powered, three units |
Applications:Xiamen Fuming Door Frame Roll Forming Machine is a perfect choice for clients who are looking for a reliable and cost effective solution for making door frame profiles. It is suitable for material thickness of 0.8-1.5mm and has a driving motor power of 15KW.
It is designed to produce high-quality door frames with exceptional accuracy and consistency. It is highly efficient and provides excellent production performance.
Technical Support and Service for Door Frame Roll Forming Machine
We provide comprehensive technical support and service for Door Frame Roll Forming Machine. Our team of experienced engineers and technicians can help you achieve optimal usage of the machine and maximize its performance.
If you have any questions or need technical support for Door Frame Roll Forming Machine, please don't hesitate to contact us. We are here to help you.
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
