Product Details:
|
| Roller Material: | Cr12, Heat Treatment, HRC58~62 | Forming Speed: | 15m/min |
|---|---|---|---|
| Control System: | PLC | Cutting Mode: | Hydraulic Cutting |
| Encoder: | Omron | Product Name: | Container Vertical Post |
| Cutting Tolerance: | ±1mm | Thickness: | 2.0mm-3.5mm |
| Highlight: | Post Container House Roll Forming Machine,Container House Roll Forming Machine Automatic | ||
Container Vertical Post Roll Forming Machine, Container House Machine
This container house roll forming machine is designed for the production of container bottom frame beam. It features an Omron encoder for precise positioning control, hydraulic cutting for efficient cutting, PLC control system for high tolerance control. The forming speed can reach up to 15m/min with stable and reliable performance.
Drawing:
| ROLL FORMING MACHINE FOR CONTAINER VERTICAL POST | |
| Material Specification | |
| Thickness | 2.0mm-3.5mm |
| Material | GI |
| Yield strength | 345MPa |
| Machine Components | |
| Feed-in and Pre-leveling Device | |
| Pre-Level Device with 4 over 3 shafts to remove the Coil-set, Manual control | |
| Roll Forming Machine | |
| Driving system | Gear/Chain |
| Roller material | Cr12, heat treatment, HRC58~62 |
| Shafts Diameter | Φ95mm |
| Motor to drive | 22KW×2 |
| Line speed of rollformer | Approx. 15m/min |
| Hydraulic Post Cutting Device | |
| Cutting type | Slug breaker |
| Cutting tool material | Cr12Mov, heat treatment |
| Hydraulci pump motor | 15KW |
| PLC Control System | |
| Function | Control quantity, punching and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Schneider |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±1mm |
| Control Voltage | 24V |
XIAMEN FUMING's Container House Roll Forming Machine is widely used in the production of container vertical post, container roof, container roof beam, container bottom beam, container bottom frame beam, container bottom frame purlin, container corner plate, container roof gutter, etc.
Technical Support and Service for Roll Forming Machine
We provide comprehensive technical support and service for Roll Forming Machine. Our team of experienced engineers and technicians can help you achieve optimal usage of the machine and maximize its performance.
If you have any questions or need technical support for Roll Forming Machine, please don't hesitate to contact us. We are here to help you.
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
