Product Details:
|
| Roller Material: | 45# Steel, Hard Chrome Coated | Forming Speed: | 15m/min |
|---|---|---|---|
| Control System: | PLC | Cutting Mode: | Hydraulic Cutting |
| Encoder: | Omron | Product Name: | Container Side Roof |
| Cutting Tolerance: | ±2mm | Thickness: | 0.3mm~1.2mm |
| Highlight: | Roof Container House Roll Forming Machine,Container House Roll Forming Machine Powerful | ||
Container Side Roof Roll Forming Machine, Container House Machine
This powerful container house roll forming machine is designed for the production of container bottom frame beam. It features an Omron encoder for precise positioning control, hydraulic cutting for efficient cutting, PLC control system for high tolerance control. The forming speed can reach up to 15m/min with stable and reliable performance.
Drawing:
| ROLL FORMING MACHINE FOR CONTAINER SIDE ROOF | |
| Material Specification | |
| Thickness | 0.3mm~1.2mm |
| Material | GI |
| Yield strength | 345MPa |
| Machine Components | |
| 5Ton*1250mm Simple Decoiler | |
| Type | No power |
| Load capacity | Max.5Tons |
| Coil Inner-diameter | 510±30mm |
| Coil width | Max.1250mm |
| Coil Outer-diameter | Max.1500mm |
| Roll Forming Machine | |
| Driving system | Gear/Sprocket driving |
| Wall plate thickness | 18mm |
| Forming stages | 10 stages |
| Roller material | 45# steel, hard chrome coated |
| Shafts Diameter | Φ75mm |
| Motor to drive | 7.5KW, frequency speed control |
| Line speed of rollformer | Approx. 15m/min |
| Hydraulic Post Punching & Cutting Device | |
| Punching & cutting type | Intergrated mould, stop to punch Φ8 and cut at the same time, slug breaker |
| Punching & cutting moulds material | Cr12Mov, heat treatment |
| Hydraulci pump motor | 4KW |
| PLC Control System | |
| Function | Control quantity, punching and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Delta |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±2mm |
| Control Voltage | 24V |
| Product Rack | Un-powered, 3 units |
XIAMEN FUMING's Container House Roll Forming Machine is widely used in the production of container vertical post, container roof, container roof beam, container bottom beam, container bottom frame beam, container bottom frame purlin, container corner plate, container roof gutter, etc.
Technical Support and Service for Roll Forming Machine
We provide comprehensive technical support and service for Roll Forming Machine. Our team of experienced engineers and technicians can help you achieve optimal usage of the machine and maximize its performance.
If you have any questions or need technical support for Roll Forming Machine, please don't hesitate to contact us. We are here to help you.
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
