Product Details:
|
| Cutting Method: | Hydraulic Cutting | Material: | GI |
|---|---|---|---|
| Roller Stations: | 22 Stations | Product Name: | Cable Tray Roll Forming Machine |
| Control System: | PLC Control | Cutting Tolerance: | ±2mm |
| Power: | 22KW | Thickness Of Material: | 1.0-2.5mm |
| Highlight: | 22KW Cable Tray Roll Forming Machine,Cable Tray Roll Forming Machine,22KW Cable Tray Forming Machine | ||
Cable Tray Roll Forming Machine is a professional roll forming equipment for producing cable trays or cable channels. It features 22 roller stations, 15m/min line speed, ±2mm cutting tolerance and PLC control system, which guarantee high production efficiency and precision. This machine is highly suitable for producing various shapes of cable trays and cable channels. It is the ideal choice for customers who are in need of high quality cable tray and cable channel production.
| ROLL FORMING MACHINE FOR CABLE TRAY PROFILE | |
| Material Specification | |
| Thickness | 1.0mm to 2.5mm |
| Material | GI |
| Yield strength | 250MPa or customized |
| Machine Components | |
| 5Ton*1250mm Hydraulic Decoiler and Pre-Leveling Device | |
| Coil inner hole expanding | Hydraulic system, 3KW pump motor |
| Driving motor | 7.5KW, with frequency inverter |
| Expanding type | Taper wedge expanding system |
| Load capacity | Max.5Tons |
| Coil inner diameter | 510±30mm |
| Coil outer diameter | Max.1600mm |
| Coil width | Max.1250mm |
| Stop/start rotation | Automatic stopping device with limited switch to assist |
| Pre-Level Device with 4 over 3 shafts to remove the Coil-set, Manual control | |
| 80 Tons Press with Servo Feeder | |
| Feeder | 3.0KW servo motor to drive |
| Stroke | 45m/min |
| Punching mold | One set, with different mold cores to get different quantity of holes punched |
| Mateiral of punching mold | Cr12Mov, heat treatment |
| Holes patten | As the drawing shown |
| Feed-in and Pre-leveling Device | |
| Two rollers for feeding in | |
| Pre-Leveling Device with 3 over 2 shafts to remove the Coil-set, Manual control | |
| Hydraulic Pre-shearing Device and Pre-punching Device | |
| Hydraulic pre-shearing device, cut to length control,to cut off the end of the final piece of sheet only | |
| Punching and notching mould | One set, to punch flange holes and flange notch |
| Share the same hydraulic station with pre-punching and pre-notching device The following picture is for your reference | |
| Roll Forming Machine | |
| Driving system | Gear/sprocket |
| Forming station | 22 stations |
| Roller material | Cr12, heat treatment |
| Shaft | Φ75mm, 45# steel, sliding parts with hard chrome coated |
| Main motor | 22KW, frequency speed control |
| Size changing | 1.1KW+0.75KW×2 |
| Line speed of rollformer | Approx. 15m/min or customized |
| Hydraulic Multi-size Cutting Device | |
| Pneumatic pin to locate, cutting off while the programmed length is reached, stop to cut | |
| Cutting device is movable on the linear rail | |
| Cutting type | Slug breaker |
| Cuttting tool | Including one set of cutting blades for all sizes |
| Cutting tool material | Cr12, Heat treatment |
| Hydraulic station | 11KW |
| PLC Control System | |
| Function | Control quantity, punching and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Schneider |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±2.0 mm |
| Control Voltage | 24V |
| Product Rack | 3 meters×2 |
XIAMEN FUMING Cable Tray Roll Forming Machine is widely used in cable channel industry for its superior performance. This machine is equipped with PLC control system, 22 stations rollers, Cr12 roller material and hydraulic cutting method. With its advanced technology, it can form 1.0-2.5mm thickness cable channel with high precision. It is also well known for its high quality and reliability.
Technical Support and Service for Cable Tray Roll Forming Machine
We provide comprehensive technical support and service for Cable Tray Roll Forming Machine. Our team of experienced engineers and technicians can help you achieve optimal usage of the machine and maximize its performance.
If you have any questions or need technical support for Cable Tray Roll Forming Machine, please don't hesitate to contact us. We are here to help you.
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
