Product Details:
|
| Drive Mode: | Gear/sprocket | Material: | PPGI |
|---|---|---|---|
| Forming Speed: | 15m/min | Control System: | PLC Control |
| Cutting Mode: | Hydraulic Cutting | Name: | Downspout Roll Forming Machine |
| Highlight: | 7.5KW Downpipe Roll Forming Machine,Downpipe Roll Forming Machine Customized,Downspout Pipe Roll Forming Machine | ||
Downpipe Roll Forming Machine for YX144-108 Profile
This Downpipe Roll Forming Machine is a kind of production line which is specifically designed and developed for the production of downpipe. It has a drive mode of gear/sprocket and a control system of PLC control that ensures reliable operation and high production efficiency. It also adopts hydraulic cutting method for more accurate and efficient cutting, with a forming speed of 15m/min. This Downpipe Roll Forming Machine ensures stable performance, high production capacity and excellent product quality.
| ROLL FORMING MACHINE FOR YX144-108 DOWNPIPE PROFILE | |
| Material Specification | |
| Thickness | 0.4mm to 0.6mm |
| Feeding width | Approx.500mm |
| Material | PPGI |
| Yield strength | 250MPa or customized |
| Machine Components | |
| 5Ton*600mm Un-powered Decoiler | |
| Load capacity | Max.5Tons |
| Coil inner diameter | 508±30mm |
| Coil outer diameter | Max. 1600mm |
| Coil width | Max.600mm |
| Option | Please refer to Decoiler on home page |
| Roll Forming Machine | |
| Driving system | Gear/sprocket |
| Forming station | 16 stations |
| Roller material | 45# steel, CNC lathes, hard chrome coated |
| Shafts Diameter | Φ75mm |
| Main motor | 7.5KW, frequency speed control |
| Line speed of rollformer | Approx. 15m/min or customized |
| Hydraulic Cutting Device | |
| Cutting type | No Blanking cut |
| Cutting tool material | Cr12, heat treatment |
| Hydraulci pump motor | 3KW |
| PLC Control System | |
| Function | Control quantity and cutting length automatically |
| PLC | Siemens |
| Touch screen | Siemens |
| Inverter | Schneider or Delta |
| Encoder | Omron |
| Cut-to-length tolerance | ≤±2 mm |
| Control Voltage | 24V |
| Product Rack | Un-powered, three units |
This roll forming machine is ideal for producing downpipe, which are widely used in residential and commercial buildings.It features a forming speed of 15m/min and PLC control system for precise and accurate cutting. The cutting mode is hydraulic. With its high production capacity, the machine can quickly and efficiently produce downpipe for drainage applications.It is perfect for any home or business that requires a durable and long-lasting drainage system.
Support and Services:
Technical Support and Service for Roll Forming Machine
We provide comprehensive technical support and service for Roll Forming Machine. Our team of experienced engineers and technicians can help you achieve optimal usage of the machine and maximize its performance.
If you have any questions or need technical support for Roll Forming Machine, please don't hesitate to contact us. We are here to help you.
Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?
A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.
XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.
Our roll forming machine is guaranteed for one year in correct operation and maintenance.
Q 2: How does the customer install the machine when it arrives?
A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.
Q 3: Does XIAMEN FUMING provide customized roll forming machines?
A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
